MEGA® Fuse Time Delay150A 32VDC Auto Link | Part No. 0298150.ZXEH | LITTELFUSE
Quantity:
Pickup available at Ashcon International Inc.
Usually ready in 24 hours
MEGA® Fuse Time Delay150A 32VDC Auto Link | Part No. 0298150.ZXEH | LITTELFUSE
Ashcon International Inc.
Pickup available, usually ready in 24 hours
3425 Laird Road
Unit #4
Mississauga ON L5L 5R8
Canada
The MEGA® Fuse is designed for high current circuit protection up to 500A with “Diffusion Pill Technology.” The MEGA® Fuse also provides time delay characteristics. Designed and patented by Littelfuse, the MEGA® Fuse is ideal for battery and alternator protection application and other heavy gauge cables requiring ultra-high current protection.
Specifications
| TYPE | DESCRIPTION |
| Category | Circuit Protection Fuses |
| Mfr | Littlefuse |
| Series | MEGA® |
| Mounting Type | Bolt Mount |
| Fuse Type | Automotive |
| Current Rating (Amps) | 150 A |
| Voltage Rating - DC | 32 V |
| Response Time | Slow Blow |
| Breaking Capacity @ Rated Voltage | 2kA |
| Melting I²t | 100000 |
| Approval Agency | UL |
| Operating Temperature |
-40° ~ 125°C |
| Size/Dimension |
1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) |
| DC Cold Resistance |
0.000352 Ohms |
